Large Capacity Low-Speed Refrigerated Centrifuge LZ-LLSC-B120

Name: Large Capacity Low-Speed Refrigerated Centrifuge LZ-LLSC-B120
Brand: Labozon
Rating: 4.0 (790 reviews)

Large Capacity Low-Speed Refrigerated Centrifuge LZ-LLSC-B120 is a floor-standing laboratory centrifuge designed for high-volume blood bank and clinical applications. It supports swing-out rotors with capacities up to 8 × 2000 ml and provides precise temperature control from –20 °C to +40 °C for sensitive sample processing. The centrifuge features programmable digital controls for RPM, RCF, time, and temperature, ensuring consistent and reproducible results. A high-performance drive system with automatic imbalance protection enables stable operation at elevated speeds. Its stainless-steel chamber and safety-locked lid ensure durability, hygiene, and operator safety during routine and intensive use.

Specifications Features Optional Accessories Applications Catalog Enquiry

Specifications

Maximum Speed	8000 rpm
Maximum RCF	14551xg
Maximum Volume	8x2000ml(16*500ml blood bag)
Timer	1-9h59min
RPM/ RCF Convert	Yes
Noise	≤ 65
Temperature Range	-20~40ºC
Acceleration / Deceleration	10 Kinds
Speed Accuracy	±20r/ min
Temperature Accuracy	±1ºC
Power Supply	AC 220V/ 110V 50HZ/60HZ
Dimensions (W x D x H)	940 × 890 × 1000mm
Weight	600 kg

Features

Large-capacity floor-standing refrigerated centrifuge
Supports swing-out rotors up to 8 × 2000 ml or equivalent blood bag configurations
Wide temperature control range from –20 °C to +40 °C for sensitive samples
High-efficiency refrigeration system for rapid cooling and thermal stability
Programmable digital control panel
Reliable imbalance detection and protection system for safe operation
Smooth acceleration and deceleration to protect delicate samples
Corrosion-resistant stainless-steel chamber
Electric lid locking with automatic safety interlock
Designed for long run times and intensive daily laboratory workflows

Optional Accessories

Rotor	Maximum Speed (rpm)	Volume	Maximum RCF (*g)
Swing rotor	4000	8 x 2000ml	5710
Swing rotor	4000	6x 2400 ml (round cup)	5330
Angle rotor	7000	6 x 1000 ml	11900
Angle rotor	4200	2 x 6 x 1000 ml	5680
Blood bag adapters		16 x 500 ml

Applications

It is widely used for Blood banks and transfusion centers, Clinical laboratories, Biotechnology and pharmaceutical laboratories for separation of whole blood into plasma, platelets, and red blood cells
