Biological Microscope LZ-BM-B100 Catalog

Biological Microscope LZ-BM-B100 has the design of Sidentopf Trinocular Head, inclined at 45°, Interpupillary 50-76 mm. Features Plan semi-apochromatic fluorescent objective. Microscope design also offers a Backward Sextuple Nosepiece, reflected transilluminator , Swing-out type achromatic condenser (N.A.0.9) with High eyepoint wide field eyepiece. Fluorescence frame, low position Coaxial coarse and fine focusing adjustment.

Optical System	Infinite color corrected optical system
Viewing Head	Siedentop trinocular head(Inverted image), 30° inclined, interpupillary distance: 50mm-76mm; splitting ratio Eyepiece: Trinocular=100:0 or 20:80 or 0:100
Eyepiece	High eyepoint wide field plan eyepiece PL10X/25mm, diopter Adjustable
Nose piece	Backward Sextuple Nosepiece ( DIC slot)
Objective	Plan semi-apochromatic fluorescent objective 4X, 10X, 20X, 40X (s), 100X
Stage	Double layers mechanical stage, size: 187mm X168mm; moving range: 80mm X55mm; precision: 0.1mm; two-way linear drive, tension adjustable
Condenser	Swing-out type achromatic condenser (N.A.0.9)
Frame	Fluorescence frame (transmitted), low-position coaxial coarse and fine adjustment, coarse adjustment distance: 25mm; fine precision: 0.001mm. With coarse adjustment stop and tightness adjustment
Reflected fluorescence illuminator	Sextuple reflected fluorescence illuminator with Iris & aperture diaphragm; filter and polarizing slot, fluorescence filters,100W mercury lamp house, filament center, Digital power controller
Transmitted illumination	12V/100W halogen lamp house for transmitted light, center pre-set, intensity adjustable

• Binocular Head, inclined at 30°
• Designed with infinite semi- plan objectives 4×, 10×, 40×, 100×
• S-LED Illumination, Brightness Adjustable
• Designed with Quadruple nosepiece
• High eyepoint wide filed plan eyepiece
• Abbe Condenser NA1.25
• Viewing head with multi-splitting ratio
• Large size rackless stage for both hands
• Modular frame with improving system compatibility
• Highly sensitive coaxial coarse and fine adjustment system
• Plan semi-apochromatic fluorescent objective

Biological Microscope used in biological, pathological, histological, bacterial, immune, pharmacological, and genetic fields.
