| Wavelength range |
360 to 780nm |
| Wavelength interval |
10nm |
| Half-band width |
5nm |
| Resolution |
0.0001 |
| Measuring range |
0 to 200% |
| Measurement condition |
d/0(scattered light source, 0 degree viewing Angle) Comply with CIE No.15, ISO 7724/1, ASTM E1164, DIN 5033 Teil7, JIS Z8722 Condition c, ASTM D1209, ASTM D5386, ASTM D6045, ASTM D6166, ASTM D1502 |
| Integrating sphere |
Φ40mm, Avian-D fully diffuse surface coating |
| Lighting source |
CLEDs (Full Band Balanced Led Light Source) |
| Inductor |
Dual optical sensor array sensor |
| Observer Angle |
2°/10° |
| Observation light source |
A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84,ID50,ID65,LED-B1,LED-B2,LED-B3,LED-B4,LED-B5,LED-BH1,LED-RGB1,LED-V1,LED-V4 |
| Displayed Results |
Pharmacopeia color number, transmission map/data, sample chromaticity value, color difference value/map, pass/fail result, color bias, color simulation, color simulation Historical data color simulation, standard sample manual input, test report |
| Measuring time |
≤ 1.5 seconds |
| Measuring optical path |
Standard: 10mm glass colorimetric dish, 50mm glass colorimetric dish (optional 33mm and 100mm glass colorimetric dish) |
| Color space |
CIE Lab, LCh, CIE Luv, XYZ, Yxy, transmissibility, Hunter Lab Munsell, MI, CMYK |
| Color difference formula |
ΔE*ab, ΔE*CH, ΔE*uv, ΔE*cmc (2:1), ΔE*cmc (1:1), ΔE*94, ΔE*02 |
| Repeatability |
Transmittance: standard deviation ≤0.08%,Colorimetric value: ΔE*ab≤0.015 standard deviation, maximum ≤0.04 |
| Interstation error |
ΔE*ab ＜ 0.25 |
| Heating function |
No |
| Screen size |
7-inch capacitive touchscreen |
| Store data |
Over 100,000 pieces of data |
| Software support |
ColorExpert, Color QC2 |
| Packaging Dimensions |
570 × 420 × 340 mm |
| Weight |
5 kg |
