Microscope

Labozon offers an extensive selection of microscopes, including biological, digital, multi-viewing, fluorescence, and phase contrast models and more. These microscopes feature high-resolution imaging, precise magnification, and advanced optics. Designed with ergonomic builds and user-friendly interfaces, Labozon microscopes support detailed observations and accurate analyses. Suitable for various applications in research, education, and clinical environments, Our instruments ensure reliable performance. Labozon’s range of microscopes provides essential tools for scientific exploration, innovation, and advancement in multiple fields

Biological Microscope

Confocal Microscope

Digital Microscope

Fluorescence Microscope

Fluorescent Biological Microscope

Inverted Biological Microscope

Inverted Fluorescence Microscope

Microscopic Camera

Monocular Microscope

Motorized Automatic Biological Microscope

Multi-Viewing Microscope

Polarizing Microscope

Slide Scanner

Stereo Microscope

Biological Microscope LZ-BM-A100

  • Optical System: Infinite optical system
  • Viewing Head: Seidentopf type, Binocular Head, inclined at 30°, Interpupillary 47-78 mm
  • Eyepiece: Diopter adjustable eyepiece WF10X / 20 mm
  • Nosepiece: Quadruple Nosepiece
  • Objective: Infinite Semi-Plan Achromatic Objectives 4X, 10X, 40X, 100X

Biological Microscope LZ-BM-A120

  • Optical System: Infinite optical system
  • Viewing Head: Compensation free, trinocular 30° inclined 360° rotation viewing head, interpupillary distance 48 to 75 mm
  • Eyepiece: Diopter adjustable eyepiece WF10X/22 mm
  • Nosepiece: Quintuple nosepiece
  • Objective: Infinite plan objective 4X, 10X, 20X, 40X (s), 100X(s, oil)

Biological Microscope LZ-BM-A130

  • Optical System: -
  • Viewing Head: Sliding Trinocular Head, inclined at 45 ºand 360 ºRotatable, interpupillary distance 55-75mm
  • Eyepiece: Wide Field Eyepiece WF10×/ 18mm
  • Nosepiece: Quadruple Nosepiece
  • Objective: Achromatic Objectives 4X, 10X, 40X, 100X
Biological Microscope LZ-BM-A140
  • Optical System: NIS60 Infinite Color Corrected Optical System
  • Viewing Head: Sidentopf Trinocular Head, inclined at 30º, interpupillary distance 47-78mm
  • Eyepiece: Super Wide Field Eyepiece SW10×/ 25mm
  • Nosepiece: Sextuple Nosepiece
  • Objective: N-PLN Plan Objectives 4X, 10X,20X, 40X, 100X
Biological Microscope LZ-BM-A150
  • Viewing Head: Sliding Trinocular Head Inclined at 45°, 360° Rotatable; Anti-Mould
  • Eyepiece: Wide Field Eyepiece WF10×、P16 ×
  • Nosepiece: Quadruple Nosepiece
  • Objective: Achromatic Objectives 4X, 10X, 40X, 100X(Oil)
  • Stage: Double Layer Mechanical Stage 140×130mm/ 75×45mm

Biological Microscope LZ-BM-A160

  • Optical System: Infinity Independent Plan Achromatic Optical System F=200mm
  • Viewing Head: Siedentopf binocular tube, Interpupillary distance 52~75mm, 30°inclined, 360° rotatable, diopter adjustable.
  • Eyepiece: WF10X/20mm, High eye-point up to 21mm.
  • Nosepiece: Quadruple Nosepiece
  • Objective: Plan Achromatic 4X, 10X, 40X, 100X

Biological Microscope LZ-BM-A170

  • Viewing Head: Sliding binocular tube, Interpupillary distance 52~75mm, 45°inclined, 360° rotatable
  • Eyepiece: WF10X/18 mm
  • Nosepiece: Quadruple Nosepiece
  • Objective: Achromatic 4X, 10X, 40X, 100X
  • Total Magnifications: With 10x eyepiece: 40×, 100×, 400×, 1000×

Biological Microscope LZ-BM-B100

  • Optical System: Infinite color corrected optical system
  • Viewing Head: Siedentop trinocular head(Inverted image), 30° inclined, interpupillary distance: 50mm-76mm; splitting ratio Eyepiece: Trinocular=100:0 or 20:80 or 0:100
  • Eyepiece: High eyepoint wide field plan eyepiece PL10X/25mm, diopter Adjustable
  • Nose piece: Backward Sextuple Nosepiece ( DIC slot)
  • Objective: Plan semi-apochromatic fluorescent objective 4X, 10X, 20X, 40X (s), 100X
Biological Microscope LZ-BM-B110
  • Optical System: NIS Infinite optical system
  • Viewing Head: Seidentopf type, Trinocular Head, inclined at 30°, Interpupillary 47-78 mm
  • Eyepiece: WF10X / 20 mm
  • Nosepiece: Quadruple Nosepiece
  • Objective: Infinite Plan Achromatic Objectives 4X, 10X, 40X, 100X
Biological Microscope LZ-BM-B120
  • Optical System: NIS60 Infinite Color Corrected Optical System
  • Viewing Head: Seidentopf Binocular Head, 30° inclined, 360° rotation, interpupillary distance: 47mm-78mm
  • Eyepiece: Super wide field plan eyepiece SW10X/22mm, diopter adjustable
  • Nose piece: Backward Quintuple Coded Nosepiece (with DIC slot)
  • Objective: Infinite Plan Achromatic Objective<br/> N-PLN 4X/NA=0.10, WD=30mm<br/> N-PLN 10X/NA=0.25, WD=10.2mm<br/> N-PLN 20X/NA=0.40, WD=12mm<br/> N-PLN 40X/NA=0.65, WD=0.7mm<br/> N-PLN 100X(Oil)/NA=1.25, WD=0.2mm

Confocal Microscope LZ-CNF-A100

  • Optical system: NIS60 Infinite optical system
  • Viewing head: Siedentopf trinocular viewing head, 45° inclined<br/> Interpupillary distance: 47 to 78 mm<br/> Eyepiece interface: Φ30 mm<br/> Fixed diopter
  • Objective: 10X Apochromatic objective; NA: 0.45, WD: 4.0 mm, Cover slip: 0.17 mm<br/> 20X Apochromatic objective: NA: 0.75, WD: 1.1mm, Cover slip: 0.17 mm<br/> 40X Apochromatic objective: NA: 0.95, WD: 0.21mm, Cover slip: 0.11 to 0.23 mm<br/> 60X Apochromatic objective: NA: 1.42, WD: 0.25mm, Cover slip: 0.17 mm (O)
  • Eyepiece: 10X/25 mm, EP 17.5mm<br/> Adjustable diopter: -5 to +5<br/> Interface: Φ30mm
  • Nosepiece: Motorized sextuple nosepiece M25×0.75

Digital Microscope LZ-DM-A110

  • Viewing Head: Binocular head, inclined at 20º , interpupillary distance 55-75 mm
  • Eyepiece: EW10X/ Ø22 mm
  • Objective: Plan achromatic objective: 1x, Zoom objectives: 0.8x-6.4x with 1:8 zoom ratio
  • Stage: working distance: 78 mm
  • Output: USB 2.0 Mini USB, HDMI

Digital Microscope LZ-DM-A120

  • Optical System: Infinity Optical System
  • Viewing Head: Trinocular Head ,Inclined at 30º, Interpupillary 48 to 75 mm
  • Eyepiece: WF10X / 20 mm
  • Nosepiece: Quadruple Nosepiece
  • Objective: Infinity Plan Achromatic Objectives: 4X, 10X, 40X, 100X
Digital Microscope LZ-DM-A130
  • Optical System: Infinite Optical System
  • Viewing Head: Seidentopf Trinocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 47-78mm, Splitting ratio 5:5, Anti-Fungus, Tube Diameter 30mm
  • Eyepiece: Extra Wide Field Eyepiece EW10×/22mm
  • Objective: NIS60 Infinite Plan Achromatic Objective 4× (N.A.:0.10, W.D.:30mm)<br/> NIS60 Infinite Plan Achromatic Objective 10× (N.A.:0.25, W.D.:10.2mm)<br/> NIS60 Infinite Plan Achromatic Objective 40× (N.A.:0.65, W.D.:1.5mm)<br/> NIS60 Infinite Plan Achromatic Objective 100× (Water, N.A.:1.10, W.D.:0.2mm)
  • Stage: Rackless stage, Size 230×150mm, Moving Range 78×54mm
Digital Slide Scanner LZ-DSS-A100
  • Capacity: 120 slides
  • Scanning Image Resolution: 0.5µm/pixel (20X) , 0.25µm/pixel (40X)
  • Motion Regulation: Linear magnetic axis motor control
  • Magnification: 20 X / 40 X
  • Light Source: LED

Digital Slide Scanner LZ-DSS-A110

  • Slide capacity: 50 slides
  • Objective lens: High-Precision 20X Plan Apochromatic Lens with NA 0.8
  • Scanning Image Resolution: 0.38μm / pixel at 20X<br/> ≤ 0.19μm / pixel at 40X
  • Scan process: Bright field imaging: fully automated / manual area selection
  • Slide loading: Automatic slide loading

Fluorescence Microscope LZ-FM-A100

  • Type: Fluorescence Microscope
  • Viewing Head: Siedentopf type trinocular head inclined at 30°, 360° rotation,Interpupillary adjustable distance 50-75 mm, Antifungal system
  • Eyepiece: WF10X/20 mm
  • Objective: Infinite plan objectives (5pcs) 4x, 10x, 20x, 40x(s), 100x(s,oil)
  • Stage: Double layer mechanical stage with removable slide holder: 180×145 mm Travel stage: 76(X)×52(Y) mm with right hand stage handle

Fluorescent Biological Microscope LZ-FBM-A100

  • Optical System: NIS60 Infinite Color Corrected Optica system
  • Viewing Head: Sidentopf Trinocular Head, inclined at 30 º,interpupillary distance 47-78mm
  • Eyepiece: Super wide field plan eyepiece SW10X/22mm, diopter adjustable
  • Nose piece: Backward Sextuple Nosepiece (with DIC slot)
  • Objective: N-PLN Plan Objectives 4X, 10X, 20X, 40X, 100X(oil)
Inverted Biological Microscope LZ-IBM-A100
  • Type: Inverted Biological Microscope
  • Optical System: Infinite Optical System
  • Viewing Head: Trinocular Viewing Head, Inclined at 45°,360° Rotatable, Interpupillary 48-75 mm
  • Eyepiece: Wide Field Eyepiece WF10×/20, Eyepiece Tube Diameter 30 mm
  • Objective: Infinite Plan Achromatic Objective 4×/0.10, WD 22 mm<br\> LWD Infinite Plan Achromatic Phase Objective: 10×/0.25 WD 6 mm<br\> LWD Infinite Plan Achromatic Phase Objective: 20×/0.4 WD 3.1 mm<br\> LWD Infinite Plan Achromatic Phase Objective: 40×/0.55 WD 2.2 mm
Inverted Biological Microscope LZ-IBM-A110
  • Type: Inverted Biological Microscope
  • Optical System: Infinite Optical System
  • Viewing Head: Trinocular Viewing Head, Inclined at 30°, Interpupillary 48-75 mm
  • Eyepiece: High-point, Extra Wide Field Eyepiece EW10×/ 22mm
  • Objective: LWD Infinite Plan Objective 4×/ 0.1, WD 18mm<br/> Infinite Plan Phase Objective PH10×/ 0.25, WD 10mm<br/> Infinite Plan Phase Objective PH20×/ 0.4, WD 5.1mm

Inverted Biological Microscope LZ-IBM-B100

  • Type: Inverted Biological Microscope
  • Optical System: NIS60 Infinite Optical System
  • Viewing Head: Trinocular head with Bertrand lens, inclined at 45°, Interpupillary 47-78mm, 3 position beam split ratio: 50/50, 100/0, 0/100
  • Eyepiece: SW 10× /25 mm, φ30 mm
  • Objective: 10× NA=0.3 WD=8.1mm Cover glass 1.2mm; 20× NA=0.45 WD=7.5-8.8mm Cover glass 0-2mm; 40× NA=0.60 WD=3-4.4mm Cover glass 0-2mm

Inverted Biological Microscope LZ-IBM-B110

  • Type: Inverted Biological Microscope
  • Optical System: NIS60 Infinite Optical System
  • Viewing Head: Trinocular head with Bertrand lens, inclined at 45°, Interpupillary 47-78mm, 3 position beam split ratio: 50/50, 100/0, 0/100
  • Eyepiece: SW 10× /25 mm, φ30 mm
  • Objective: Infinite Plan semi-APO phase contrast Objective<br/> 10× NA=0.3 WD=8.1mm Cover glass 1.2mm<br/> 20× NA=0.45 WD=7.5-8.8mm Cover glass 0-2mm<br/> 40× NA=0.60 WD=3-4.4mm Cover glass 0-2mm

Inverted Fluorescence Microscope LZ-IFM-A100

  • Type: Inverted Fluorescence Microscope
  • Viewing Head: Trinocular Head Inclined at 30°, Interpupillary distance: 48 to 75 mm
  • Eyepiece: High-point, Extra Wide Field Eyepiece EW10×/ 22
  • Objective: LWD Infinite Plan Objective 4×/0.1, WD 18mm; LWD Infinite Plan Objective 40×/0.6, WD 2.6mm; Infinite Plan Phase Objective PH 10×/0.25, WD 10mm; Infinite Plan Phase Objective PH 20×/0.4, WD 5.1 mm
  • Stage: Plain stage 160×250 mm; Glass Insert; Auxiliary Stages70×180 mm
Inverted Fluorescence Microscope LZ-IFM-B100 (Motorized)
  • Optical system: NIS60 Infinite Optical System
  • Viewing Head: Trinocular Head with Bertrand lens, inclined at 45o Interpupillary 47- 78 mm, 3 position beam spilt ratio: 50/50, 100/0, 0/100
  • Eyepiece: SW10X/25 mm, φ30mm
  • Phase Contrast Objective: Infinite plan semi-APO, 10x, 20x,40x; NA= 0.3,0.45,0.60; WD= 8.1 mm, 7.5-8.8mm, 3-4.4 mm; Cover glass=1.2 mm, 0-2mm, 0-2mm
  • Stage: Motorized 3 layer mechanical stage, stage dimension: 340x230 mm, movement range 130(X) x 100(Y) mm, Flexible Knob, Different small sizes stages could be attached to main stage
Microscopic Camera LZ-UMC-A100
  • Sensor: 8.3M/IMX585©
  • Sensor Size: 1/1.2” (11.14x6.26)
  • Pixel sixe: 2.9x2.9μm
  • G sensitivity Dark signal: 5970(mV/lx/s) 0.13mv with 1/30s
  • FPS/ Resolution: 45@3840x2160 70@1920x1080

Microscopic Camera LZ-UMC-A110

  • Sensor: 3.1M/IMX265(C, GS)
  • Sensor Size: 1/1.8” (7.07x5.30)
  • Pixel sixe: 3.45 x 3.45μm
  • G sensitivity Dark signal: 1146mv with 1/30s<br/> 0.15mv with 1/30s
  • FPS/ Resolution: 53@2048x1536<br/> 85@1024x768

Microscopic Camera LZ-UMC-A120

  • Sensor: 8.3M/IMX485©
  • Sensor Size: 1/1.2”(11.14x6.26)
  • Pixel size: 2.9 x 2.9 μm
  • G sensitivity Dark signal: 2188mv with 1/30s<br/> 0.15mv with 1/30s
  • FPS/ Resolution: 43@3840x2160<br/> 66@1920x1080

Microscopic Camera LZ-UMC-A130

  • Sensor: 18M/SONY Special©
  • Sensor Size: 1/2.2” (5.86x4.46)
  • Pixel sixe: 1.2 x1.2μm
  • G sensitivity Dark signal: 130mv with 1/30s<br/> 0.1mv with 1/30s
  • FPS/ Resolution: 17@4880×3720<br/> 40@2448×1836<br/> 50@1728×1296
Microscopic Camera LZ-UMC-A140
  • Sensor Model: Sony IMX334( C ) <br/> CMOS color sensor
  • Sensor Dimension: 1/1.8"inch ( 7.68 × 4.32 ) mm
  • Pixel: 2.0 × 2.0 µm
  • Sensitivity Level / Baseline Signal: 505 mv with 1/30s<br/> 0.1mv with 1/30s
  • Frame Rate: 30 FPS at 3840 × 2160 resolution across HDMI, Network, and USB connections
Monocular Microscope LZ-MM-A100
  • Headpiece: Monocular Head Inclined at 45°, 360° Rotation
  • Magnification: 40×, 100×, 400×, 1000×
  • Viewing Lens: Wide-Angle Ocular Lens WF10X/18mm
  • Revolving Nosepiece: Quadruple Nosepiece
  • Objective Lens: Semi-Plan Achromatic Objective 4×, 10×, 40×

Motorized Automatic Biological Microscope LZ-MBM-A100

  • Optical System: NIS60 Infinite color collected optical system
  • Viewing Head: Seidentopf type, Trinocular Head, inclined at 30°,Interpupillary 47-78 mm splitting ratio Eyepiece: Trinocular=100:0 or 20:80 or 0:100
  • Eyepiece: Super wide field plan eyepiece SW10X/25mm,diopter adjustable
  • Nose piece: Motorized Backward Sextuple Nosepiece (with DIC slot)
  • Objective: N-PLN Plan Objective4X, 10X,20X, 40X, 100X

Multi-Head Microscope LZ-MH-A100

  • Type: Multi- Viewing Microscope (5 Persons)
  • Viewing Head: Sliding Binocular Head, inclined at 45°, ID 55-75mm, Anti-mould (5pcs)
  • Eyepiece: Wide Field Eyepiece WF10x/18 mm (10pcs)
  • Objective: Achromatic Objective 4×, 10×, 40×, 100×
  • Stage: Double Layers Mechanical Stage 140×140mm/ 75×50mm

Multi-Head Microscope LZ-MH-A110

  • Type: Multi- Viewing Microscope
  • Viewing Head: Sliding Binocular Head, inclined at 45°, ID 55-75mm, Anti-mould (2pcs)
  • Eyepiece: Wide Field Eyepiece WF10x/18 mm (4pcs)
  • Objective: Achromatic Objective 4×, 10×, 40×, 100×
  • Stage: Double Layers Mechanical Stage 140×140mm/ 75×50mm
Polarizing Microscope LZ-PM-A110
  • Optical System: Infinite Optical System
  • Viewing Head: Seidentopf Trinocular Head, inclined at 30°, 360° Rotatable, Interpupilary Distance: 48-76mm, Light distribution (both) 100: 0 (100% for eyepiece), 80:20 (80% for trinocular head and 20% for eyepiece)
  • Eyepiece: WF10×/22mm, WF10×/22 mm (Reticule 0.1mm)
  • Objective: Infinite Strain Free Plan Achromatic Objective (Transmitted): 4×/0.10 W.D=12.1mm, 10×/0.25 W.D=4.64mm, 20×/0.40(S) W.D=2.41mm, 40×/0.66(S) W.D=0.65mm
  • Nosepiece: Backward Quintuple nosepiece, center adjustable
Stereo Microscope LZ-SM-A110
  • Type: Stereo Microscope
  • Viewing Head: Upright Binocular Viewing Head, Interpupillary Distance 55-75mm, diopter adjustment ±5dp on left ocular-tube, Tube diameter 23.2mm
  • Eyepiece: WF10X20mm(optional:WF5X20 mm, WF15X15 mm, WF20X10 mm
  • Objective: LWD 2X, 80 mm(optional: 6X,66mm, 1X, 57mm, 4X, 57mm, 2X, 80mm
  • Stage: White and black Plate: 60 mm

Stereo Microscope LZ-SM-A120

  • Type: Stereo Microscope
  • Viewing Head: Upright Binocular Viewing Head, Interpupillary Distance 55-75mm, diopter adjustment ±5dp on left ocular-tube, Tube diameter 23.2mm
  • Eyepiece: WF10X20mm(optional:WF5X20 mm, WF15X15 mm, WF20X10 mm
  • Objective: LWD 2X, 80 mm(optional: 6X,66mm, 1X, 57mm, 4X, 57mm, 2X, 80mm
  • Stage: White and black Plate: 60 mm

Stereo Microscope LZ-SM-A130

  • Type: Stereo Microscope
  • Viewing Head: Upright Binocular Viewing Head, Interpupillary Distance 55-75mm, diopter adjustment ±5dp on left ocular-tube, Tube diameter 23.2mm
  • Eyepiece: WF10X20mm(optional:WF5X20 mm, WF15X15 mm, WF20X10 mm
  • Objective: LWD 2X, 80 mm(optional: 6X,66mm, 1X, 57mm, 4X, 57mm, 2X, 80mm
  • Stage: White and black Plate and Frosted glass : 95 mm

Stereo Microscope LZ-SM-A210

  • Type: Stereo Microscope
  • Viewing Head: Binocular Viewing Head, 45° Inclined, I D:55-75mm, diopter adjustment ±5dp on left ocular-tube, Tube diameter 23.2mm
  • Eyepiece: WF10X20 mm(OPTIONAL: WF5X20mm, WF15X15mm, WF20X10 mm
  • Objective: LWD2X, 80 mm(OPTIONAL: 1X, 57mm, 3X, 61mm, 4X, 57mm, 6X, 66 mm
  • Stage: White and black Plate: 60 mm
Stereo Microscope LZ-SM-A220
  • Type: Stereo Microscope
  • Viewing Head: Binocular Viewing Head, 45° Inclined, I D:55-75mm, diopter adjustment ±5dp on left ocular-tube, Tube diameter 23.2mm
  • Eyepiece: WF10X20 mm(OPTIONAL: WF5X20mm, WF15X15mm, WF20X10 mm
  • Objective: LWD2X, 80 mm(OPTIONAL: 1X, 57mm, 3X, 61mm, 4X, 57mm, 6X, 66 mm
  • Stage: White and black Plate: 60 mm
Stereo Microscope LZ-SM-A230
  • Type: Stereo Microscope
  • Viewing Head: Binocular Viewing Head, 45° Inclined, I D:55-75mm, diopter adjustment ±5dp on left ocular-tube, Tube diameter 23.2mm
  • Eyepiece: WF10X20 mm(OPTIONAL: WF5X20mm, WF15X15mm, WF20X10 mm
  • Objective: LWD2X, 80 mm(OPTIONAL: 1X, 57mm, 3X, 61mm, 4X, 57mm, 6X, 66 mm
  • Stage: White and black Plate and Frosted glass : 95 mm

Stereo Microscope LZ-SM-A300

  • Type: Stereo Microscope
  • Viewing Head: Binocular Viewing Head, 45° Inclined, Interpupilary Distance 55-75mm, diopter adjustment ±5dp on left ocular-tube, Tube diameter 23.2mm
  • Eyepiece: WF10×/20mm(optional: WF5X20 mm, WF15X15 mm, WF20X10 mm
  • Objective: Long Working Distance: 1X,230 mm(optional: 0.5X, 250mm 2X, 80mm
  • Light Source: Incident 3W LED

Stereo Microscope LZ-SM-A410

  • Type: Stereo Microscope
  • Viewing Head: Binocular Viewing Head, 45° Inclined, Interpupilary Distance 55-75mm, Un-rotatable
  • Eyepiece: WF10X20mm(optional: WF5X20mm, WF15X15mm, WF20X10mm
  • Objective: LWD 2X,4X, 57mm(optional: 1X,2X;1X,3X
  • Light Source: 12V/ 10WTransmitted halogen light

Stereo Microscope LZ-SM-A440

  • Type: Stereo Microscope
  • Viewing Head: Binocular Viewing Head, 45° Inclined, Interpupilary Distance 55-75mm, 360° Rotatable
  • Eyepiece: WF10X20mm(optional: WF5X20mm, WF15X15mm, WF20X10mm
  • Objective: LWD: 2X,4X, 76mm(optional: 1X,2X;1X,3X
  • Light Source: 12V/ 10W Incident halogen light
Stereo Microscope LZ-SM-A510
  • Type: Stereo Microscope
  • Viewing Head: Binocular Viewing Head, at 45°, 360° rotatable, Interpupillary adjusting distance 55-75mm(optional: Binocular Viewing Head, at 60°, 360° rotatable, Interpupillary adjusting distance 55-75mm)
  • Magnification: 5X-240X
  • Focusing: Coarse Focus, Focusing Range 100mm
  • Eyepiece: Diopter Adjustment: WF10×/23mm, WF20X12mm, WF30X8mm, WF10X eyepiece with cross hair) (optional: WF10X22mm,WF10X20mm,WF15X16m,
Stereo Microscope LZ-SM-A520
  • Type: Stereo Microscope
  • Viewing Head: Trinocular Viewing Head, at 45°, 360° rotatable, Interpupillary adjusting distance 55-75mm(optional: Binocular Viewing Head, at 60°, 360° rotatable, Interpupillary adjusting distance 55-75mm)
  • Magnification: 5X-240X
  • Focusing: Coarse Focus, Focusing Range 100mm
  • Eyepiece: Diopter Adjustment: WF10×/23mm, WF20X12mm, WF30X8mm, WF10X eyepiece with cross hair) (optional: WF10X22mm,WF10X20mm,WF15X16m,

Zoom Stereo Microscope LZ-ZSM-A140

  • Type: Zoom Stereo Microscope
  • Viewing Head: Trinocular Tube, Splitting methods are 0:100,50:50
  • Magnification: 0.8X-6.4X
  • Optical System: Infinite parallel zoom optical system
  • Zoom Ratio: 1 ; 8

Zoom Stereo Microscope LZ-ZSM-B210

  • Type: Zoom Stereo Microscope
  • Viewing Head: Binocular head, at 45°, rotatable 360°, I D: 54-75mm, diopter adjustment on both eyepieces
  • Magnification: 0.67X-4.5X
  • Optical System: Greenough
  • Zoom Ratio: 1:6.7 WD:105 mm

Zoom Stereo Microscope LZ-ZSM-B220

  • Type: Zoom Stereo Microscope
  • Viewing Head: Trinocular head, at 45°, rotatable 360°, I D:54-75mm, diopter adjustment on both eyepieces
  • Magnification: 0.67X-4.5X
  • Optical System: Greenough
  • Zoom Ratio: 1:6.7 WD:105 mm
Zoom Stereo Microscope LZ-ZSM-B230
  • Type: Zoom Stereo Microscope
  • Viewing Head: Binocular head, at 45°, rotatable 360°, ID: 54-75mm, diopter adjustment on both eyepieces
  • Magnification: 0.67X-4.5X
  • Optical System: Greenough
  • Zoom Ratio: 1:6.7 WD:105 mm
Zoom Stereo Microscope LZ-ZSM-B240
  • Type: Zoom Stereo Microscope
  • Viewing Head: Trinocular head, at 45°, rotatable 360°, ID: 54-75mm, diopter adjustment on both eyepieces
  • Magnification: 0.67X-4.5X
  • Optical System: Greenough
  • Zoom Ratio: 1:6.7 WD:105 mm

Zoom Stereo Microscope LZ-ZSM-C100

  • Type: Zoom Stereo Microscope
  • Viewing Head: 30 degree inclined trinocular head; fixed light distribution, binocular: trinocular=50: 50; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw
  • Zoom range: 0.63X-8X, click stop for 0.63×, 0.8×, 1×, 1.25×, 1.6×, 2×, 2.5×, 3.2×, 4×, 5×, 6.3×, 8×, with built-in aperture diaphragm
  • Optical System: Infinite parallel Galileo zoom optical system
  • Zoom Ratio: 1:12.5
Enquiry form

2025 © All Rights Reserved by Labozon.com
