Tissue Grinder Machine LZ-TGM-A101

Tissue Grinder Machine LZ-TGM-A101 is designed for rapid and efficient grinding, crushing, mixing, and cell disruption of biological samples, enabling extraction and purification of DNA, RNA, and proteins. Its dual-slide vertical oscillation mechanism provides thorough and stable grinding while minimizing cross-contamination. It supports a wide range of samples, including animal and plant tissues, microorganisms, food, pharmaceuticals, plastics, and environmental materials.

Tissue Grinder Machine LZ-TGM-A101 - Specifications

Maximum Speed 500–2300 rpm
Grinding Jar Standard: 24 × 2 ml
Optional: 96×2 ml, 48×2 ml, 32×2 ml, 16×5 ml, 8×10 ml, 2×15 ml, 2×25 ml, 2×50 ml
Grinding Procedure Dry, wet & low-temperature grinding
Oscillation Mode Up-and-down vertical oscillation
Grinding Time 0–120 s per segment
Display 7-inch OLED touchscreen
Grinding Balls Stainless Steel
Power Consumption 180 W
Power Supply AC 110–220 V, 50/60 Hz
External Dimensions 265 × 405 × 510 mm
Package Dimensions 375 × 530 × 670 mm
Net Weight 29 kg
Gross Weight 41 kg

Tissue Grinder Machine LZ-TGM-A101 - Key Features

Tissue Grinder Machine LZ-TGM-A101 - Applications

Suitable for the preparation and homogenization of animal tissues, plant tissues, microorganisms, food and pharmaceutical samples, plastics, polymers, and environmental samples.
