Hot Plate Magnetic Stirrer LZ-MSH-E130

Name: Hot Plate Magnetic Stirrer LZ-MSH-E130
Brand: Labozon
SKU: LZ-MSH-E130
Availability: InStock
Rating: 5.0 (876 reviews)

Hot Plate Magnetic Stirrer LZ-MSH-E130 a tabletop device with 20 L maximum capacity offers temperature range at 340˚C. Hotplate designed with round stainless-steel work plate having ceramic coating, provides good chemical resistance performance and a digital display offers clear view of temperature, time and speed of hot plate. This hot plate with magnetic stirrer features speed range of 100 to 1500 rpm, 550 W of heating power, and a PT1000 temperature sensor.

Hot Plate Magnetic Stirrer LZ-MSH-E130 - Specifications

Work Plate Dimension	135× 135 mm
Work Plate Material	Stainless Steel cover with ceramic
Motor	Brushless DC motor
Max. Stirring Quantity	20 L
Max. magnetic Bar(length)	80mm
Speed Range	100 to 1500 rpm
Hot Plate Temperature	340°C
Ambient Temperature	5-40°C
Temperature control accuracy	±1°C(<100°C) ±1%(>100°C)
Display	LCD
Dimensions	160× 280× 85 mm
Power Consumption	550W
Electrical Supply	AC 100-200/200-240V 50/60Hz
Weight	2.8 kg

Hot Plate Magnetic Stirrer LZ-MSH-E130 - Key Features

Designed with dual digital LED display
Brushless DC motor is maintenance free and explosion-proof
Digital temperature control with max. temperature at 340°C
Maximum speed ranges offered is 1500 rpm
Magnetic hotplate stirrer with 20L maximum capacity
Safety circuits comes with overheating protection
Alarm warning in case the temperature exceeds above 50˚C even if the hotplate is turned off
Wide range timer function from 1min to 99h59min
Can control external temperature by connecting to PT1000 temperature sensor, accuracy is at ±0.2°C
Stainless steel work plate with ceramic coating provides good chemical-resistant performance
Remote function provides PC control and data transmission
Wide variety of accessories are available

Hot Plate Magnetic Stirrer LZ-MSH-E130 - Applications

Hotplate Magnetic Stirrer used in physical and chemical, bio-chemical analysis, bio-pharmaceuticals and other fields for different scientific research and quality testing of materials.
