Drying Oven LZ-HDO-A100

Name: Drying Oven LZ-HDO-A100
Brand: Labozon
SKU: LZ-HDO-A100
Availability: InStock
Rating: 5.0 (888 reviews)

Drying oven LZ-HDO-A100 is a PID microprocessor temperature controller drying oven with a 40 L chamber capacity. It provides a fast ramping rate and stability during operation. Its operational temperature range is RT+10 to 250℃ and is designed with a large LCD screen to display more data at the same time. Equipped with stainless steel chamber, the outer shell of steel with plastic coating and dual-layer toughened glass observation window. It is suitable for industrial and mining enterprises, laboratories, and scientific research institutes for desiccation, torrefaction, wax-melting, and sterilization.

Drying Oven LZ-HDO-A100 - Specifications

Chamber Volume	40 L
Temperature Range	RT+10 to 250℃
Display Resolution	0.1℃
Temperature Stability	±1℃
Temperature Uniformity	±2.5%
Display	LCD display
Shelves	2 pcs
Timing Range	0 to 5999 min
Internal dimension (W×D×H)	350 × 300 × 400 mm
External dimension (W×D×H)	505 × 655 × 600 mm
Power consumption	850 W
Power supply	220 V, 50 Hz
Net Weight	40 kg
Gross Weight	52 kg

Drying Oven LZ-HDO-A100 - Key Features

Designed with PID microprocessor temperature controller system
The material used polished stainless-steel chamber
Equipped with a 25 mm instruction connection hole on the left side of the chamber for easy testing operation and temperature
Auto-controller of fan speed to prevent damage to the samples
Designed with a large LCD screen to display more data at the same time
Self-check function easy to identify problems
Offers programmable controller 7 periods 63 steps, 0 to 5999 min for each period, fan speed 0 to 100% adjustable
Dual-layer glass door, large viewing window
Independent audible and visible temperature-limiting alarm system ensures experiments run safely
Over-temperature and temperature difference alarms
Semicircular arcs at corners for easy cleaning and the space between the shelves in the chamber is adjustable

Drying Oven LZ-HDO-A100 - Optional Accessories

Accessories no.	Name
1	Printer
2	RS-485

Drying Oven LZ-HDO-A100 - Applications

Drying Oven is used for glassware desiccation, laboratory sample, food, chemical materials heat denaturalization, heat induration, moisture elimination, biomedical and other instruments sterilization; electronic components torrefaction and aging.
