Trio Block Thermal Cyclers LZ-TTC-T10

Name: Trio Block Thermal Cyclers LZ-TTC-T10
Brand: Labozon.com
Rating: 4.8 (859 reviews)

Trio Block Thermal Cyclers LZ-TTC-T10 have designed 6 Peltier heating units to heat up the sample with 3 variations in temperature specifically to enhance PCR efficiency and accuracy. This device can process more than 1000,000 cycles and can save 10000 PRC run data. It is equipped with a graphical 8-inches TFT color touch-screen which is a friendly graphic user interface. With flexible ramp rate 5 ℃/s and gradient temperature control 0 to 100℃. The Wi-Fi function, USB, printer enables you to transfer PCR run files. It can accommodate 3× (32×0.2 ml) wells or tubes. It enables optimal operational settings with windows operations system and can monitor the operations via mobile connectivity.

Specifications Features Applications Catalog Enquiry

Specifications

Capacity	3×(32×0.2 ml )
Temperature Range	0 to 100℃
Heating Rate	5 ℃/s
Cooling Rate	4 ℃/s
Uniformity	≤ ± 0.3 ℃
Accuracy	≤ ± 0.2 ℃
Display Resolution	0.1 ℃
Temperature Control	Block Tube
Ramping Rate Adjustable	0.1 to 5 ℃
Gradient Temperature Range	NA
Gradient Spread	NA
Hot Lid Temperature	30 to 110 ℃
Hot Lid Height Adjustable	Step less Adjustable
Number Of Programs	10000 +(USB FLASH)
No. Of Step	30
No. Of Cycle	100
Increment/Decrement Time	1 Sec to 600 Sec
Temperature Increment/Decrement	0.1 to 10.0℃
Pause Function	Yes
Auto Data Protection	Yes
Holding	4 ℃
Touchdown Function	Yes
Long Pcr Function	Yes
LAN To Computer	Yes
Display	LCD
Interface	USB2.0 , LAN
Power	600 W
Voltage	85 to 264VAC , 47 to 63Hz
Dimensions(L×W×H)	390×270×255 mm
Weight	9 kg

Features

It has graphical 8-inches touch screen display which enables the user to change the commands
Uniform heating with 3 different temperature of the samples is achieved with Peltier heating units with more than 1,000,000 cycles
It is well built with anodizing technology with aluminum block treatment which makes the durable and corrosion resistant
Maximum heating rate is 5 ℃/s with temperature range of 0 to 100 ℃
It has the capability to accommodate 120×80 mm wells with moveable hot lid which can fit different sizes of tubes
It has the internal flash memory to store the 10000 files data for analysis
The connectivity between computer is via USB port and mini printer and can store the GLP data after every step to get reliable results
All the operations are controlled by a computer software system which instrument PCR protocols and also has in built 11 standard protocols
It has power of operation recovery option which helps in continuing the same command after a recovering from power cut
The user can access to his individual experimental data by setting a password and data management system
To satisfy the customers need it is installed with special feature like the user can add sample while the process is going on to encounter different variations
The user will be sent notifications via email about the process to alert when operation ends
